| PHYSICAL |
|
|
| |
Form Factor |
Rackmount |
| |
Weight |
15 lbs (6.8 kg) |
| |
Dimensions |
Inches: 17"W x 13" D x 3.5" H
Millimeters: 431.8 x 381 x 133.35 |
| |
Dimensions (with rack ears) |
Inches: 19" W x 13" D x 3.5" H
Millimeters: 482.6 W x 330.2 D x 88.9 H |
| |
Inputs (Physical) |
Eight (8) bi-directional 3G mini-SDI inputs/outputs with full-size BNC adapter cables; or
Up to eight (8) inputs; six (6) inputs and two (2) outputs |
| |
Output (Physical) |
N/A |
| |
Max. Output Resolutions |
4K/30p (SDI/HDMI);
4K/59.94p IP/recording |
| |
4K Ready |
Yes |
| |
Compatible Input Formats |
SDI:
525159.94 NTSC, 625150 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080150, 1080159.94, 1080i60 |
| |
CPU |
AMD Ryzen |
| |
GPU |
NVIDIA with resizable bar RAM enabled |
| |
RAM |
32GB |
| STORAGE |
|
|
| |
Built-In |
1TB NVMe M.2 SSD |
| |
Expandable |
Four (4) 2.5" hot/swap SSD bays for additional storage* |
| NETWORKING |
|
|
| |
On-Board |
(1) gigabit ethernet LAN |
| LIVE STREAMING |
|
|
| |
Software |
vMix 4K |
| |
vMix Reference |
Topaz |
| |
Transitions |
CrossZoom, Cube, CubeZoom, Cut, Fade, Fly, FlyRotate, Merge, Slide, Zoom, VerticalWipe, VirtualSlide, Wipe, and two (2) custom Stinger channels. |
| |
Audio Mixing |
Built-in audio mixer allows for independent control/monitoring of all audio sources with Compressor, Delay, EQ, Follow (Auto Mixing), Gain, Mute, and Solo |
| |
Video Conferencing |
vMix Call: Up to four (4) callers/guests. Actively bring in guests onto your live show using only a web browser and webcam
Zoom: Create and join zoom meetings directly from vMix (vMix 27 or newer) |
| |
Replay |
Built-in, single-camera instant replay system with continuous recording in full HD and playback.
Two-channel playback also is included with the ability to show audiences two (2) camera angles side-by-side or in almost any arrangement you can think of. |
| |
Social Media |
Integrated application for live or queued insertion of Facebook, X (formerly Twitter) or internat relay chat (IRC) feeds. User can both approve AND control content from web-connected devices |
| |
Multiview |
Each input includes five (5) “multi-view” overlay channels for creating complex Mix/Effects, incorporate logo "bugs", lower thirds, text or titles, in combination |
| |
Telestrator |
Turn any modern browser into a Telestration device. Telestrator is an input with a transparent background that can be drawn on using a web browser. |
| |
Other |
Downstream Keyer: 4 DSKs / overlays with individual transitions, alpha channel and custom scaling/positioning.
Desktop Capture: Ability to grab screen capture from local/remote PC-Mac sources included
Touch Screen Web Interface: Control vMix remotely using the vMix Web Controller on your Surface, iPad, iPhone, Android or other touch screen device using the built in web interface
Professional color correction & monitoring tools
SRT Support: Control vMix remotely using the vMix Web Controller on your Surface, iPad, iPhone, Android or other touch screen device using the built-in web interface |
